24v 2.5a 3a wall models
100-240V AC input 50/60HZ, DC 24V 2.5A 3A output, 72 Watt max wattage
Convert 100-240V AC to 24V DC, widely use for SMD2835 3528 5050 RGB LED strip lights, LED string, Air purifier devices, Audio/Video power supply
Please be kindly informed that the total wattage of your device should not exceed the max wattage（72 Watt) of this adapter
1 x 24V power supply with 5ft power cord, 1 x 5.5/2.1 DC female barrel connector ( optional )
With 3 year warranty, and our seller support team always stand behind our products in any way, so please contact us for solution if you have any quality problems
- Description
| body size | 92*46*30mm |
| Input Rated Voltage | 86Vac～264Vac |
| Input Frequency Range | 47Hz～63Hz |
| Input Current | 0.8A(Max) |
| Input Inrush Current | 50A |
| Efficiency | 88%, level VI |
| DC Output 1 | 24v ± 5% / 2.5a, 3a |
| DC Output 2 | 12v ± 5% / 5a ,6a ( optional ) |
| DC Output Power | 72w ( max ) |
| Ripple and Noise | ≤120Mv |
| Turn On Delay Time | ≤3S (AC:110V and full load) |
| Standard | UL/CUL FCC CE CB |
| DC cable length | 1.5m 2464 type ( optional ) |
| DC connector | 5.5*2.1/2.5*12mm ( optional ) |
| Dielectric Withstand Voltage | A IEC320 3 pin input---output(FG)3K Vac 1 m |
| Protection | OVP ,OCP,SCP,OTP |
| Leakage Current | ≤5Ma |
| Operating Temperature Range | 0℃----+55℃ |
| Storage Temperature | -20℃----+85℃ |
